Satellite antenna systems.
Within only a few years, the commercial ASTRA and EUTELSAT satellites have been able to go a long way to meet subscribers‘ requirements to receive even more TV and radio programmes.
From the outset, our satellite dishes found a ready market and achieved a leading market position. Today, millions of people take it for granted that they are able to receive analogue or digital satellite TV, last but not least due to the reliability, the quality and the ease of use our products provide.
We offer a complete line of innovative satellite technology for:
* Professional solutions
* Individual and community reception systems for private customers
* High quality reception for mobile use (camping and caravaning)
The efficiency of our SAT products - whether parabols or planar antennas, or electrical components, distribution systems, analogue or digital receivers - have time and again completely convinced our customers, retailers and independent test persons. Kathrein products regularly come out first in product tests, especially in the category covering the price / performance ratio.
Our motto "Quality leads the way" has proved to be extremely successful, especially in this high growth market.
We are the global market leader in the field of satellite reception technology, and will do our utmost to remain ahead of the market competition.
Kathrein CAP 910
Kathrein’s latest automatic satellite TV system comes with a High-Definition receiver and is, without any doubt, the most sophisticated model of its kind available. Using GPS technology to position the dish and adjust the L.N.B., its speed and precision are unrivalled. This extreme accuracy gives the CAP 910 a performance equivalent to other systems with considerably bigger dishes.
A twin L.N.B. is standard enabling a SKY receiver to be easily connected (although Sky+ features are not supported) and the CAP 910 comes with its own sophisticated, fully featured receiver which enables reception of dozens of different satellites and up to 4,000 channels. A common access slot is provided so that subscription cards (not SKY cards) can also be used. This receiver also acts as the system’s controller, saving space and ensuring a neat and tidy installation. The receiver is simple to use via the on-screen display and even a first-time user should be able to use the system within minutes of installation.
This system is complete and, after installation, ready to go. It only requires an additional receiver if you wish to receive subscription channels from Sky or another broadcaster. All BBC, ITV and Channel 4 channels as well as Channel 5 - along with hundreds of other English language ones and thousands of foreign channels - can all be received without any additional cost.
In addition, there’s a USB port for recording to an external hard drive or memory stick.
The High-Definition capability of the receiver means that, when it’s connected to an H.D. TV, programmes being shown in H.D. will be seen as they are intended by the programme makers. Even on small screen TVs, picture quality can be stunning!
|
Operating voltage: |
12V |
|
Dish type: |
High-gain parabolic dish |
|
Dish size: |
77cm |
|
L.N.B. type: |
Twin LNB: SKY+ receivers can be used with the CAP 910 but will not offer the same features as when used at home. For instance, it is not possible to watch one channel while recording another. |
|
Mounting method: |
Fixes to roof with Sikaflex and screws |
|
Dish colour: |
Cream |
|
Search method: |
Can only be used when vehicle is stationary. Uses G.P.S. to establish vehicle’s position, thereby making location of the desired satellite quick and extremely accurate |
|
Search controller dimensions: |
280mm x 45mm x 185mm |
|
Typical search time – after first use: |
Less than one minute |
|
Satellite search options: (available satellites will vary according to geographical location) |
Pre-programmed for satellites including: Astra 2, Eurobird, Astra 1, Hotbird, Atlantic Bird, Hispasat, Thor, Nilesat, Turksat, Eutelsat, Hellas Sat, Telecom |
|
Receiver options: |
Comes with Kathrein’s UFS 740 receiver which is also used to control the system. Any satellite receiver including FTA & FREESAT receivers can be used as well. |
|
Remote control: |
Yes |
|
Weight of dish & motor: |
18.9 Kgs |
|
Current consumption during search: |
Approx. 4 Amps |
|
Current consumption when in use and search completed: |
Receiver uses approx. 26 watts (2 Amps on 12V) |
|
Dish height when down: |
23 cms |
|
Space required for operation of dish: |
X |
|
Warranty: |
2 Years |
|
Receiver features |
Record facility using USB hard-drive or memory stick. High / Standard definition |
Click on image to enlarge
Kathrein CAP 710
This mid-sized satellite TV system from Kathrein comes with a High-Definition receiver giving superb picture quality on even small-screen TVs with H.D. capability. In addition, there’s a USB port for recording to an external hard drive or memory stick. This receiver also acts as the system’s controller. It has an HDMI output and can be operated via a remote sensor so that it can be hidden away out of sight, saving space and ensuring a neat and tidy installation.
The system is simple to use via the on-screen display and even a first-time user should be able to use the system within minutes of installation. The receiver enables reception of dozens of different satellites and up to 4,000 channels. All BBC, ITV and Channel 4 channels as well as Channel 5 - along with hundreds of other English language ones and thousands of foreign channels - can all be received without any additional cost. A common access slot is provided so that subscription cards (not SKY cards) can also be used. This system is complete and, after installation, ready to go.
Please note: that this system cannot be used with any other receiver than the one supplied
|
|
12V |
|
Dish type: |
High-gain parabolic dish |
|
Dish size: |
60cm |
|
L.N.B. type: |
Universal single LNB |
|
Mounting method: |
Fixes to roof with Sikaflex and screws |
|
Dish colour: |
Cream |
|
Search method: |
Can only be used when vehicle is stationary. |
|
Search controller dimensions: |
280mm x 45mm x 185mm |
|
Typical search time – after first use: |
Less than one minute |
|
Satellite search options: (available satellites will vary according to geographical location) |
Astra 2, Eurobird, Astra 1, Hotbird, Atlantic Bird, Hispasat, Thor, Nilesat, Turksat, |
|
Receiver options: |
Can only be used with Kathrein’s UFS 940 FTA receiver |
|
Remote control: |
Yes |
|
Weight of dish & motor: |
9.7 Kgs |
|
Current consumption during search: |
Approx. 1.5 Amps |
|
Current consumption when in use and search completed: |
Approx. <0.1 Amp |
|
Other features: |
N/A |
|
Dish height when down: |
23 cms |
|
Space required for operation of dish: |
566 mm lowered turning circle. 270mm Lowered Height |
|
Warranty: |
2 years |
|
Receiver included |
Yes |
|
Receiver features |
Record facility using USB hard-drive or memory stick. High + Standard definition |
Click on image to enlarge
Kathrein CAP 610
Kathrein’s popular diamond-shaped dish satellite TV system has been updated and now comes with a High-Definition receiver giving superb picture quality on even small-screen TVs with H.D. capability. In addition, there’s a USB port for recording to an external hard drive or memory stick.This receiver also acts as the system’s controller. It has an HDMI output and can be operated via a remote sensor so that it can be hidden away out of sight, saving space and ensuring a neat and tidy installation.
The system is simple to use via the on-screen display and even a first-time user should be able to use the system within minutes of installation. The receiver enables reception of dozens of different satellites and up to 4,000 channels. All BBC, ITV and Channel 4 channels as well as Channel 5 - along with hundreds of other English language ones and thousands of foreign channels - can all be received without any additional cost. A common access slot is provided so that subscription cards (not SKY cards) can also be used.This system is complete and, after installation, ready to go.
Please note: that this system cannot be used with any other receiver than the one supplied
|
|
12V |
|
Dish type: |
Planar type |
|
Dish size: |
50cms (equivalent of 60cm) |
|
L.N.B. type: |
Universal single LNB |
|
Mounting method: |
Fixes to roof with Sikaflex and screws |
|
Dish colour: |
Cream |
|
Search method: |
X |
|
Search controller dimensions: |
X |
|
Typical search time – after first use: |
Less than one minute |
|
Satellite search options: (available satellites will vary according to geographical location) |
Astra 2, Eurobird, Astra 1, Hotbird, Atlantic Bird, Hispasat, Thor, Nilesat, Turksat, |
|
Receiver options: |
Can only be used with supplied UFS 740 receiver |
|
Remote control: |
Yes |
|
Weight of dish & motor: |
13.8 Kgs |
|
Current consumption during search: |
Approx. 1.2 Amps |
|
Current consumption when in use and search completed: |
X |
|
Dish height when down: |
21 cms |
|
Space required for operation of dish: |
X |
|
Warranty: |
2 years |
|
Receiver included |
Yes |
|
Receiver features |
Record facility using USB hard-drive or memory stick. High + Standard definition |
Click on image to enlarge
Manual Satellite Antenna Systems
Kathrein’s square satellite antenna uses a unique method of picking up satellite signals.
Its shape makes it easy to transport and stow and this makes it a popular choice for use with motorhomes and caravans.
Please Note: A skew plate is not required for this system
Dish type: Planar antenna
Dish size: 50cm (equivalent to 60 cm offset dish)
L.N.B. type: Universal (suitable for analogue & digital)
Mounting option/s: Tripod or through-roof
Colour: Cream
Click on image to enlarge
Kathrien HDM 140 Sat angled mast for BAS 60 for caravans
Kathrien HDM 141 Sat angled mast; shortened model for installation in caravans with BAS 60
Kathrein HDS 150 Stand alone Sat angled mast for BAS 60
